American Pattern Blocks Double Sheave
Description
Product Code |
Size |
Wire Diameter |
SWL (Tonnes) |
A |
B |
C |
D |
E |
Weight (kgs/each) |
|---|---|---|---|---|---|---|---|---|---|
APB12 |
300mm |
20-22mm |
5 |
730mm |
300mm |
130mm |
57mm |
115mm |
44 |
APB14 |
350mm |
20-24mm |
8 |
880mm |
350mm |
150mm |
60mm |
150mm |
56 |
APB16 |
400mm |
24-26mm |
10 |
1000mm |
400mm |
180mm |
65mm |
155mm |
100 |
